17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1

I'm Online Chat Now

17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1

17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1
17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1 17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1 17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1

Large Image :  17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1

Product Details:
Place of Origin: China
Brand Name: OTTO
Model Number: B42
Payment & Shipping Terms:
Minimum Order Quantity: 200 pcs(10pcs/thinkness)
Price: USD0.3-0.6/pcs
Packaging Details: plastic box and cartons
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 50000pcs/month

17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1

Description
Material: Steel Color: Silver
Dimension: Φ3/Φ5.1 Specification: 1.34-1.66 MM( 0.020±0.002)
Difference: 0.02mm Total Number Of Thicknesses: 17 Types
Quantity Of Complete Set: 170 Pieces Application: Bosch Common Rail Injector
High Light:

adjusting shim

,

Injector Shim



17 Types Engine Common Rail Bosch Injector Shims

B42 Φ3 / Φ5.1



Name: Injector shims, Common rail injector adjusting shims

Model: B42






Specification: Φ3/Φ5.1

Thickness range: 1.34-1.66mm

Thickness difference. 0.02mm/spec

Total type: 17 types

Total quantity per set: 170pcs

Application: for the adjusting of Bosch common rail injectors








This B42 is for Bosch common rail injectors. You could also order based on the thickness you need(10pcs/thickness).



We supply common rail adjust shims for Bosch and Denso common rail injectors:



* For Bosch injectors:

B11, B12, B13, B14, B15, B16, B17, B22, B25, B26, B31, B37, B40, B41, B42,



* For Denso injectors:

B21, B23, B24, B27, B45



You could choose the specification for each model based on what you need.

We also select the most popular models and specification as a set for you, our customers, to try:



A: Whole series Shims sets including the both Bosch and Denso shims:



* Ordering Code: TQ10 Set including B11/B12/B13/B14/B16/B22/B25/B26/B27/B31



- 10 models applied to both Bosch and Denso common rail injectors

- 10 types of most popular thickness of each model

- 10pcs for each thickness



   in total 1,000pcs in the set



* Ordering Code: TD05 Set including B11/B12/B13/B14/B16/B22/B25/B26/B27/B31



- 10 models applied to both Bosch and Denso common rail injectors

- 10 types of most popular thickness of each model

-  5pcs for each thickness



   in total 500pcs in the set



B: Shims sets for Bosch common rail injectors:



* Ordering Code: TB07 including B13/B14/B16/B22/B25/B26/B31



 - 7 models applied for Bosch common rail injectors

 - 10 types of most popular thickness of each model

 - 10pcs for each thickness



 in total 700pcs in the set



C: Shims sets for Denso common rail injectors:



* Ordering Code: TD04 including B21/B23/B24/B27



 -  4 models applied for Denso common rail injectors

 - 10 types of most popular thickness of each model

 - 10pcs for each thickness



 in total 400pcs in the set








FULL SET OF B42 SHIMS WITH 17 TYPES, 10PCS/TYPE, IN TOTAL 170PCS





ITEM ORDERING CODE SIZE QTY PICTURE & SPECIFICATION
1 B42 1.340 10PCS







17 Types Engine Common Rail Bosch Injector Shims B42 Φ3 / Φ5.1 0





 B42

SPECIFICATION: Φ3/Φ5.1 BOSCH
0.02MM DIFFERENCE/THICKNESS
1.340-1.660  MM(0.020±0.004)
IN TOTAL 17 THICKNESSES




2 B42 1.360 10PCS
3 B42 1.380 10PCS
4 B42 1.400 10PCS
5 B42 1.420 10PCS
6 B42 1.440 10PCS
7 B42 1.460 10PCS
8 B42 1.480 10PCS
9 B42 1.500 10PCS
10 B42 1.520 10PCS

11 B42 1.540 10PCS
12 B42 1.560 10PCS
13 B42 1.580 10PCS
14 B42 1.600 10PCS
15 B42 1.620 10PCS
16 B42 1.640 10PCS
17 B42 1.660 10PCS








Competitive Advantage:

  • control product precision dimension within 0.002mm
  • no less than 5 times from finishing process to finished product
  • Reasonable Price
  • Good after Service
  • International standards
  • Selected and used by research institutes
  • Supplied to fuel injector manufacturers
  • First choice for maintenance stations
  • Ranking No.1 among the similar products in the market



Description:



Features of ALTURA high-precision adjusting shims:



1. Product precision

Precision is the key requirement for adjusting shims.Accurate adjustment for fuel quantity si completed depending on grouping of products.We adopt high precision optical ruler to control lapping dimension, and can control product precision dimension within 0.002mm.We finish grouping by inspecting one product with two products inside dustfree workshop.One product is measured for no less than 5 times from finishing process to finished product (Testing methods:use high precision digital display micrometer to measure conformity between actual dimension and required dimension,and whether the dimension for same grouped products is same or not.)



2. Geometric tolerance

Geometric tolerance of adjusting shims is directly related to the maintenance quality of fuel injectors.Main geometri tolerance requirement for adjusting shims is depth of parallelism.Large shim will affect product tightness while small shim will affect reliability and stability of products.We adopt high-precision double-sided  lapping machine to ensure and control depth of parallelism for products within 0.002mm.Adoption of one-time forming process better ensures product axiality(Testing methods:use parallelism tester and deflection instrument to test parallelism depth and axiality respectively)



 3. Material quality and hardness

Material quality and hardness of adjusting shims affect durability and stability of products.We choose high quality material and advanced thermal treatment equipments/technology.



4. Cleanliness



Product cleanliness can be better ensured due to multi-channel ultrasonic cleaning, dust-free workshop

packaging and plastic case sealed packaging.
